DuPont XP 77 IG UF Membrane Reliable Pre-Treatment Solution for Power Plant Ultrapure Water Systems
Produktdetails:
| Herkunftsort: | CHINA |
| Markenname: | Dupont |
| Zertifizierung: | CE |
| Modellnummer: | Integratec ™ XP 77 IG (ehemals SFP 2880XP) |
Zahlung und Versand AGB:
| Min Bestellmenge: | 1 PC |
|---|---|
| Preis: | verhandelbar |
| Verpackung Informationen: | Standard -Exportpackung |
| Lieferzeit: | 5- 8 Arbeitstage |
| Zahlungsbedingungen: | T/t |
| Versorgungsmaterial-Fähigkeit: | 60000 Einheiten pro Monat |
|
Detailinformationen |
|||
| XP 77 Ig Effektiver Membranbereich:: | 8 Zoll | XP 77 IG -Durchflussrate:: | 2,0–8,5 m³/h (8,8–37,6 gpm) |
|---|---|---|---|
| XP 77 IG Max -Futterdruckdruck:: | 90,65 psi bei 20 ° C | Nenner Porendurchmesser von XP 77 IG:: | 0,03 µm |
| Max -Rückspülendruck:: | 26 psi (36 psi) | Max. Betrieb TMP dieses Moduls:: | 2.1 bar |
| Max -Betriebsluftsteuerfluss dieses Moduls:: | 12 nm3/h | Naocl (max.) Dieses Moduls:: | 2.000 mg/l |
| Bescheinigungen:: | ISO 9001, NSF, CE | Anwendung:: | Produktion von reinem Wasser |
| Vorteile:: | Hohe Effizienz · Energieeinsparung | Highlight:: | Dupont XP 77 UF -Membran, energiesparende UF -Wassermembran, Dow UF -Membran für reines Wasser |
Produkt-Beschreibung
The DuPont XP 77 IG UF Membrane is an advanced ultrafiltration (UF) membrane engineered to deliver exceptional pre-treatment performance for ultrapure water (UPW) production in power plants. As a critical first step in power plant water purification—prior to processes like reverse osmosis (RO) or ion exchange—it effectively removes suspended solids, colloids, bacteria, and particulate matter, safeguarding downstream equipment and ensuring consistent UPW quality for boiler feedwater, steam generation, and turbine cooling systems.
This membrane operates on a precision ultrafiltration mechanism: its proprietary polyethersulfone (PES) or advanced polymer matrix features a uniform microporous structure that retains contaminants as small as 0.01 microns while allowing pure water molecules to pass through. In power plant applications, it processes raw water or treated water sources, reducing turbidity and microbial load to near-zero levels. This pre-treatment not only prevents fouling of RO membranes and ion exchange resins but also enhances the efficiency of subsequent purification steps, ensuring the final UPW meets strict power industry standards (e.g., low silica, TOC, and ionic content).
Key Specifications of DuPont XP 77 IG UF Membrane
|
Specification |
Details |
|
Membrane Material |
Advanced Polyethersulfone (PES) or Proprietary Polymer |
|
Pore Size |
~0.01 Microns |
|
Operating Temperature Range |
5–40°C (41–104°F) |
|
Operating Pressure Range |
0.2–2.0 Bar (2.9–29.0 psig) |
|
Maximum Turbidity (Feed Water) |
≤ 10 NTU |
|
Water Flux (Typical) |
15–30 L/m²·h (LMH) at Standard Conditions |
|
Chemical Resistance |
Compatible with pH 2–11; Resistant to Common Cleaning Agents |
For power plants, the DuPont XP 77 IG UF Membrane offers standout advantages: its robust design ensures long-term durability even in harsh feedwater conditions, minimizing replacement frequency and operational downtime. The membrane’s high contaminant rejection rate reduces maintenance costs for downstream equipment, while its energy-efficient operation aligns with power plant sustainability goals. Additionally, it supports easy integration into existing water treatment systems, with flexible module configurations to match varying plant water demand.
Trusted for its reliability and performance, the DuPont XP 77 IG UF Membrane is the ideal pre-treatment choice for coal-fired, natural gas, or renewable energy power plants, ensuring consistent ultrapure water supply to protect critical infrastructure and optimize overall plant efficiency.
